Catalog / Switchboard Labels / Reflective PV SW Label
03-02-G-0002
Reflective PV SW Label
MATERIAL
Laser Engraved Traffolyte
DIMENSIONS
100×100mm
COLOUR-WAY
DL#13a06a
MOUNTING
3M Adhesive Tape
DESCRIPTION
Reflective PV SW Label
Genuine 3M Adhesive
Reflective
100mm Round
Australian Made
--
PV Identification Label
A circular, green reflective sign marked "PV" — required at the main switchboard and meter panel on every grid-connected solar installation, so approaching emergency responders can immediately identify that a live PV system is present before starting work.
Since AS/NZS 5033:2021, the base "PV" mark on its own is no longer enough — it must carry a suffix identifying the isolation method present at that point: DP (disconnection point), SW (load-break disconnection switch), or AC (microinverter system). Minimum 100mm diameter, green reflective, durable for the service life of the system.
Sources:
QUANTITY
QuantityUnit Price
1–9 units$2.38
10–99 units$2.19
100–199 units$1.95
200+ units$1.81
Unit price$2.38
$2.62 inc GST
Total (1 units)$2.38($2.62 inc)
VISAMASTERCARDAMEXEFT
Australian Made · Fast Nationwide Dispatch, 24–48hrs
